 1. Product pro?le 1.1 General description Planar Maximum Ef?ciency General Application (MEGA) Schottky barrier recti?ers with an integrated guard ring for stress protection, encapsulated in small Surface-Mounted Device (SMD) plastic packages. 1.2 Features n Forward current: IF ≤ 1A n Reverse voltage: VR≤ 20 V n Very low forward voltage n Small SMD plastic packages 1.3 Applications n Low voltage recti?cation n High ef?ciency DC-to-DC conversion n Switch mode power supply n Reverse polarity protection n Low power consumption applications 1.4 Quick reference data [1] Pulse test: tp≤ 300μs;δ≤0.02. PMEG2010EH; PMEG2010EJ; PMEG2010ET 1 A very low VF MEGA Schottky barrier recti?ers Rev. 04 — 20 March 2007 Product data sheet Table 1. Product overview Type number Package Con?guration NXP JEITA JEDEC PMEG2010EH SOD123F - - single PMEG2010EJ SOD323F SC-90 - single PMEG2010ET SOT23 - TO-236AB single Table 2. Quick reference data Symbol Parameter Conditions Min Typ Max Unit IF forward current Tsp ≤55 °C --1A VR reverse voltage - - 20 V VF forward voltage IF = 1000 mA [1] - 420 500 mV |
